FUSETEK FLNR-025 Powr-Gard® Current-Limiting Fuse Time-Delay Class RK5 25 A, 250 VAC/125 VDC
fusflnr025
FUSETEK FLNR-025 Powr-Gard® Current-Limiting Fuse Time-Delay Class RK5 25 A, 250 VAC/125 VDC
Manufacturer:FUSETEK
Manufacturer #:FLNR-025
Description
Littelfuse FLNR series fuses have been the superior UL Class RK5 dual-element time-delay fuses, and are the most widely used class of fuses. FLNR series fuses provide excellent protection for all types of circuits especially those containing motors. Applications are service entrance switches, transformers, switchboard main and feeder switches, motor control center mains and motor branch circuits, individual fused combination motor controllers, distribution panelboards, industrial control panels, protection of fully-rated panelboards and loadcenters and all general purpose circuits.
Specifications
| Brand Name | Littelfuse | Sub Brand | Powr-Gard® |
| Item Name | Current-Limiting Fuse | Type | Time-Delay |
| Series | FLNR | Voltage Rating | 250 VAC/125 VDC |
| Amperage Rating | 25 A | Interrupt Rating | 200 kA at AC, 20 kA at DC |
| Fuse Class | Class RK5 | Body Style | Cylindrical, Rejection |
| Mounting Type | Holder | Terminal Connection | Ferrule |
| Element Type | Dual | Indication | Non-Indicating |
| Response Time | 10 sec | Dimensions | 9/16 in dia x 2 in L |
| Standards | UL File Number E81895, CSA File Number LR29862, Federal Specification WF-1814, CE Certified | Application | For Service Entrance Switches, Transformers, Switchboard Mains and Feeders, Motor Control Central Mains and Motor Branch Circuits and All General Purpose Circuits |
Packages
| 10 - rarr_unit_1 |
